Engine
- Engine type
- Liquid-cooled, 4-stroke Single
- Compression ratio
- 12.5:1
- Valve system
- DOHC, 4 valves
- Bore x stroke
- 96.0 x 62.1 mm
- Displacement
- 449 cm³
- Fuel system
- Fuel injection: Ø 44 mm x 1
- Ignition
- Digital DC-CDI
- Starting System
- Electric
- Lubrication
- Forced lubrication, semi‑dry sump
Transmission
- Transmission
- 5-speed, return
- Clutch
- Wet multi-disc, manual
- Primary Reduction Ratio
- 2.727 (60/22)
- Gear Ratios 1st
- 1.750 (28/16)
- Gear Ratios 2nd
- 1.412 (24/17)
- Gear Ratios 3rd
- 1.188 (19/16)
- Gear Ratios 4th
- 1.000 (19/19)
- Gear Ratios 5th
- 0.875 (21/24)
- Final drive
- Chain
- Final reduction ratio
- 3.846 (50/13)
Brakes & Suspension
- Brakes, front
- Single semi-floating 270 mm petal disc. Caliper: Dual-piston
- Brakes, rear
- Single 250 mm petal disc. Caliper: Single-piston
- Suspension, front
- 49 mm inverted telescopic fork with adjustable compression and rebound damping.
- Suspension, rear
- New Uni-Trak with adjustable dual-range (high/lowspeed) compression damping, adjustable rebound damping and adjustable preload.
Frame & Dimensions
- Frame type
- Perimeter, aluminium
- Trail
- 122 mm
- Wheel travel front
- 305 mm
- Wheel travel rear
- 307 mm
- Tyre, front
- 80/100-21 51M
- Tyre, rear
- 120/80-19 63M
- Steering angle L/R
- 42° / 42°
- L x W x H
- 2,185 x 820 x 1,265 mm
- Wheelbase
- 1,485 mm
- Ground clearance
- 340 mm
- Fuel capacity
- 6.2 litres
- Seat height
- 955 mm
- Curb mass
- 110.2 kg
